The aluminium parts for the heater came in so it was time for a test fit before powder coating. After removing the AC I was left with an issue of how to get the air from the outlet in the crash structure to the heater. With the evaporator removed the route to the heater was compromised. There is also no recirculation now. Anyway in a similar fashion to the plastic housing I removed on clean up I drew a two part housing that sits behind the heater, actually the heater clamps it in once attached properly. It's shape gives me the room to accommodate the battery. Some ducting is attached which runs to an aluminium clamp which I will Velcro to the outlet (on the plastic housing) in the crash structure, it's a tight fit already, perfect in fact. The second part to securing the housing behind the heater involves the washer bottle bracket, this sits snugly next to it once bolted into place. There is also a riv-nut I can use behind the top part of the housing, so absolutely no movement whatsoever.



The battery bracket courtesy of George, I had to slightly reengineer but that too once attached to the washer bottle bracket will not move at all. Not shown is how I've modified the washer bottle bracket further, you'll have to wait for the finished image :-)





















Back out again and off for powder coating. I will draft exclude inside the housing before properly installing btw and will post the finished images up later. Worked out well though hey....

And some more bits you may recognise.
